RealityKit 입문 - 측정앱 만들기

꽤 정확하다! 25cm가 나옴!

---

거리 측정

sim_distance() 사용 UI와 연동

import Foundation
import RealityKit
import SwiftUI

class Coordinator {
    var arView: ARView?
    var startAnchor:AnchorEntity?
    var endAnchor:AnchorEntity?

    lazy var measurementButton: UIButton = {
        let button = UIButton(configuration: .filled())
        button.setTitle("0.00", for: .normal)
        button.translatesAutoresizingMaskIntoConstraints = false
        button.isUserInteractionEnabled = false
        return button
    }()

    lazy var resetButton: UIButton = {

        let button = UIButton(configuration: .gray(), primaryAction: UIAction(handler: { [weak self] action in
            guard let arView = self?.arView else { return }
            self?.startAnchor = nil
            self?.endAnchor = nil

            arView.scene.anchors.removeAll()
            self?.measurementButton.setTitle("0.00", for: .normal)
        }))



        button.translatesAutoresizingMaskIntoConstraints = false
        button.setTitle("Reset", for: .normal)
        return button

    }()

    @objc func handleTap(_ recognizer: UITapGestureRecognizer) {
        guard let arView = arView else { return }
        let tappedLocation = recognizer.location(in: arView)

        let results = arView.raycast(from: tappedLocation, allowing: .estimatedPlane, alignment: .horizontal)

        if let result = results.first {
            if startAnchor == nil {
                startAnchor = AnchorEntity(raycastResult: result)
                print("startAnchor의 위치: \(startAnchor?.position(relativeTo: nil))")
                let box = ModelEntity(mesh: MeshResource.generateBox(size: 0.01), materials: [SimpleMaterial(color: .green, isMetallic: true)])

                startAnchor?.addChild(box)
                guard let startAnchor = startAnchor else {
                    return
                }
                arView.scene.addAnchor(startAnchor)
            }else if endAnchor == nil {
                endAnchor = AnchorEntity(raycastResult: result)
                print("endAnchor의 위치: \(endAnchor?.position(relativeTo: nil))")

                let box = ModelEntity(mesh: MeshResource.generateBox(size: 0.01), materials: [SimpleMaterial(color: .red, isMetallic: true)])
                endAnchor?.addChild(box)

                guard let endAnchor = endAnchor,
                    let startAnchor = startAnchor
                else {
                    return
                }
                arView.scene.addAnchor(endAnchor)

                /// calculate the distance
                let distance = simd_distance(startAnchor.position(relativeTo: nil), endAnchor.position(relativeTo: nil))

                measurementButton.setTitle(String(format: "%.2f meters", distance), for: .normal)
            }
        }
    }

    func setupUI() {

        guard let arView = arView else { return }

        let stackView = UIStackView(arrangedSubviews: [measurementButton, resetButton])
        stackView.axis = .horizontal
        stackView.spacing = 8
        stackView.distribution = .fillEqually
        stackView.translatesAutoresizingMaskIntoConstraints = false

        arView.addSubview(stackView)

        stackView.centerXAnchor.constraint(equalTo: arView.centerXAnchor).isActive = true
        stackView.bottomAnchor.constraint(equalTo: arView.bottomAnchor, constant: -60).isActive = true
        stackView.heightAnchor.constraint(equalToConstant: 44).isActive = true

    }

}
